Packing into your rental car, van, box truck or trailer
The Vault Pro is 54 × 19 × 29 in (137 × 48 × 74 cm).
With the rear seats folded it goes into most hatchbacks, SUVs and minivans, and any cargo van, box truck or trailer.
Pick your rental below, or measure your own.
Hatchbacks and wagons
Rear seats folded flat, case laid on its side: most hatch openings are lower than the case is tall.
Compact and midsize SUVs
Rear seats folded. Standing up where the tailgate opening is tall enough, otherwise on its side.
Minivans and full-size SUVs
Usually standing up, often with the second row still in place.
Cargo vans
Standing up between the wheel arches, with room for several.
Box trucks
Standing up, strapped to the wall rails. A 10 ft truck takes a team’s worth.
Illustrations drawn from the Vault Pro CAD model inside generic vehicle outlines; not specific models.
Will it fit your rental?
Toyota RAV4: Fits on its side
With the rear seats folded
Standing upWon’t fit: opening height short by 1 in
On its sideFits, at least 9 in to spare
To scale. Case on its side; the cyan line is the rear opening.
Length
Width
Height
Seats up
34 in (86 cm)
44 in
30 in
Seats folded
73 in (185 cm)
44 in
30 in
Rear opening
42 in
28 in
Vault Pro
54 in
19 in
29 in
✓ We have loaded a Vault Pro into a compact SUV ourselves (and a customer reports the same), though not necessarily this model.
Third-party estimate · model years not stated by the source · itemfits.com estimate · read 2026-10-14
Honda CR-V: Fits standing up
With the rear seats folded
Standing upFits, at least 3 in to spare
On its sideFits, at least 13 in to spare
To scale. Case standing; the cyan line is the rear opening.
Length
Width
Height
Seats up
37 in (94 cm)
42 in
32 in
Seats folded
70 in (178 cm)
42 in
32 in
Rear opening
42 in
38 in
Vault Pro
54 in
19 in
29 in
✓ We have loaded a Vault Pro into a compact SUV ourselves (and a customer reports the same), though not necessarily this model.
With the rear seats folded (largest layout; the source does not say which seats are folded)
Standing upFits, at least 7 in to spare
On its sideFits, at least 17 in to spare
To scale. Case standing; the cyan line is the rear opening.
Length
Width
Height
Seats folded
72 in (183 cm)
50 in
37 in
Rear opening
49 in
36 in
Vault Pro
54 in
19 in
29 in
✓ We have loaded a Vault Pro into a minivan or cargo van ourselves, though not necessarily this model.
Third-party estimate · model years not stated by the source · itemfits.com estimate · read 2026-10-14
Chrysler Pacifica: Fits standing up
With the rear seats folded (largest layout; the source does not say which seats are folded)
Standing upFits, at least 8 in to spare
On its sideFits, at least 18 in to spare
To scale. Case standing; the cyan line is the rear opening.
Length
Width
Height
Seats folded
88 in (224 cm)
49 in
37 in
Rear opening
49 in
37 in
Vault Pro
54 in
19 in
29 in
✓ We have loaded a Vault Pro into a minivan or cargo van ourselves, though not necessarily this model.
Third-party estimate · model years not stated by the source · itemfits.com estimate · read 2026-10-14
Honda Odyssey: Fits standing up
With the rear seats folded (largest layout; the source does not say which seats are folded)
Standing upFits, at least 11 in to spare
On its sideFits, at least 19 in to spare
To scale. Case standing; the cyan line is the rear opening.
Length
Width
Height
Seats folded
92 in (234 cm)
48 in
40 in
Rear opening
49 in
41 in
Vault Pro
54 in
19 in
29 in
✓ We have loaded a Vault Pro into a minivan or cargo van ourselves, though not necessarily this model.
Third-party estimate · model years not stated by the source · itemfits.com estimate · read 2026-10-14
Kia Carnival: Fits standing up
With the rear seats folded (largest layout; the source does not say which seats are folded)
Standing upFits, at least 7 in to spare
On its sideFits, at least 17 in to spare
To scale. Case standing; the cyan line is the rear opening.
Length
Width
Height
Seats folded
87 in (221 cm)
49 in
36 in
Rear opening
49 in
36 in
Vault Pro
54 in
19 in
29 in
✓ We have loaded a Vault Pro into a minivan or cargo van ourselves, though not necessarily this model.
Third-party estimate · model years not stated by the source · itemfits.com estimate · read 2026-10-14
Toyota Camry (any midsize sedan): Won’t fit
With the rear seats up
Standing upWon’t fit: cargo length short by 19 in
On its sideWon’t fit: cargo length short by 19 in
To scale. Case standing; the cyan line is the rear opening.
Length
Width
Height
Seats up
35 in (89 cm)
44 in
21 in
Rear opening
41 in
18 in
Vault Pro
54 in
19 in
29 in
Third-party estimate · model years not stated by the source · itemfits.com estimate · read 2026-10-14
Ford Transit (regular length, low roof): Room inside — check the door
Cargo area
Standing upRoom inside; door size not published — check the opening
On its sideRoom inside; door size not published — check the opening
To scale. Case on its side; rear opening not published.
Length
Width
Height
Cargo area
126 in (320 cm)
54.8 in
56.9 in
Rear opening
—
—
Vault Pro
54 in
19 in
29 in
✓ We have loaded a Vault Pro into a minivan or cargo van ourselves, though not necessarily this model.
Dealer or spec-database figures · 2014-on generation, regular length low roof; third-party spec database (Ford's own page could not be read) · vandimensions.com · read 2026-10-14
Mercedes-Benz Sprinter (144 in, standard roof): Fits standing up
Cargo area
Standing upFits, at least 32 in to spare
On its sideFits, at least 24 in to spare
To scale. Case standing; the cyan line is the rear opening.
Length
Width
Height
Cargo area
133 in (338 cm)
53 in
68 in
Rear opening
61 in
61 in
Vault Pro
54 in
19 in
29 in
✓ We have loaded a Vault Pro into a minivan or cargo van ourselves, though not necessarily this model.
Dealer or spec-database figures · 2024 cargo van, 144 in wheelbase, standard roof; Mercedes-Benz dealer specifications · Mercedes-Benz dealer specifications · read 2026-10-14
Ram ProMaster (low roof): Not enough data — measure
Cargo area
Standing upNot enough data (no cargo length, opening height)
On its sideNot enough data (no cargo length, opening height)
Length
Width
Height
Cargo area
—
56 in
65 in
Rear opening
60 in
—
Vault Pro
54 in
19 in
29 in
✓ We have loaded a Vault Pro into a minivan or cargo van ourselves, though not necessarily this model.
Published by the maker or rental company · ram.com cargo page (width, doors); low-roof height from Ram brochure · Ram ProMaster cargo · read 2026-10-14
U-Haul 10 ft truck: Fits standing up
Cargo area
Standing upFits, at least 38 in to spare
On its sideFits, at least 42 in to spare
To scale. Case standing; the cyan line is the rear opening.
Length
Width
Height
Cargo area
119 in (302 cm)
76 in
74 in
Rear opening
71 in
67 in
Vault Pro
54 in
19 in
29 in
Published by the maker or rental company · U-Haul published figures (approximate, per U-Haul) · U-Haul · read 2026-10-14
U-Haul 15 ft truck: Fits standing up
Cargo area
Standing upFits, at least 48 in to spare
On its sideFits, at least 58 in to spare
To scale. Case standing; the cyan line is the rear opening.
Length
Width
Height
Cargo area
180 in (457 cm)
92 in
86 in
Rear opening
87 in
77 in
Vault Pro
54 in
19 in
29 in
Published by the maker or rental company · U-Haul published figures (approximate, per U-Haul) · U-Haul · read 2026-10-14
53 ft dry van trailer: Fits standing up
Cargo area
Standing upFits, at least 79 in to spare
On its sideFits, at least 69 in to spare
To scale. Case standing; the cyan line is the rear opening.
Length
Width
Height
Cargo area
630 in (1600 cm)
99 in
108 in
Rear opening
98 in
108 in
Vault Pro
54 in
19 in
29 in
Published by the maker or rental company · typical interior of a 53 ft dry van; individual trailers vary · typical 53 ft dry van interior · read 2026-10-14
Car, SUV and minivan figures are estimates from a third-party fit tool, not the manufacturers, who publish cargo
volume but not the floor length and tailgate opening that decide this. Trims and model years differ, so we only
say Fits with at least 3 in to spare on every dimension; anything closer says measure first.
If you have a tape measure, the checker below gives you a firm answer for the car in front of you.
Measure your own
Fold the rear seats, then measure in inches: the floor from the back of the front seats to the tailgate, the narrowest
width (usually between the wheel arches), the height inside, and the rear opening’s width and height.
Box trucks and 53 ft trailers
For a team or an event, a 53 ft dry van (about 630 × 99 × 108 in inside) has floor space for 11 rows of 5 cases, 55 to a
layer. A 10 ft rental box truck takes several standing up between its rails. Strap every case to the walls.
